As the consumption of
electrical energy increases, the concern regarding the
environmental impact of generating electricity is
growing significantly. Today power plants play a key
role in converting various forms of energy into
electrical power. However, the imposing threat to the
environment is one of the disadvantages of today’s power
generation methods. The world’s supply of the sun and the air is huge
and infinite in comparison to the other forms of energy
that are being utilized in modern power plants. The
MAHST team strived to design a unit where there is no
fossil fuel to be burned, no water to be boiled, and no
high cost production to be considered.
The MAHST consists of a
parabolic reflector that is capable of creating a
centralized focal point in order to heat a Stirling
engine. The sun is also used directly to provide solar
energy to a PV panel. A tracking system is used to
maximize the exposure of the Stirling engine and the
solar panel to the sun. MAHST’s tracking system follows
the sun using timing devices. The idea behind this is
that the length of the day and the position of the sun
are already known, and this information can be
programmed into a microcontroller. At the end of the day, the reflector will return
to its original position. This method completely
controls the dish, and eliminates variables that might
interfere if another system were in place.
MAHST project includes a
battery and a charge controller. The battery system will
be used to store the energy generated from the solar
panel and the Stirling engine. Once the energy is
stored, it can easily be accessed through the use of
voltage regulators. A charge controller is implemented
in MAHST to control the voltage going to the battery.
In order to keep track of
the amount of power being generated, a monitoring system
is designed for MAHST. The monitoring system enables the
user to easily see the power being generated by the
panel, the voltage stored in the battery, and the
battery’s temperature. This part of the design will be
implemented using microcontrollers, a display unit,
current sensors, voltage sensors, and a temperature
sensor.
The
MAHST will have two power
outlets: a 5V DC for powering USB devices and a 12V DC.
MAHST as its name stands for will deliver a mini at-home
solar thermal power generator and will offer a great
deal of savings in utility bills for every household
around the country.
